Ubiquiti USW-Pro-XG-24 Pro XG 24-Port L3 10GbE Etherlighting Switch

Power and Flexibility for Enterprise Networks

The Ubiquiti USW-Pro-XG-24 is a professional-grade Layer 3 Etherlighting™ switch designed to deliver next-generation speed, capacity, and resilience. With a versatile mix of 10 GbE, 2.5 GbE, and 25G SFP28 ports, it is built for high-performance enterprises, data centers, and large-scale deployments requiring robust switching, routing, and redundancy features.

Highlights

• 24-Port High-Speed Switching: 16× 10 GbE, 8× 2.5 GbE, and 2× 25G SFP28 ports.

• Layer 3 Features: Inter-VLAN routing, static routing, DHCP server and relay.

• Massive Capacity: 460 Gbps switching, 230 Gbps non-blocking throughput, 342 Mpps forwarding.

• Redundancy Built-In: Supports DC backup with USP RPS input.

• Advanced Security: Includes ACLs, DHCP snooping, MAC isolation, and 802.1X control.

• Enterprise Reliability: Etherlighting™ visibility, storm control, jumbo frames, and IGMP snooping.

• Rackmount Ready: 1U steel enclosure with 19" four-post rack compatibility.

• Smart Management: 1.3" touchscreen LCM display for intuitive monitoring.

Key Features

High-Performance Switching

• Flexible Ports: Combination of 2.5 GbE, 10 GbE, and 25G uplinks for diverse workloads.

• Enterprise Throughput: 460 Gbps switching capacity and 230 Gbps non-blocking throughput.

• Scalability: Supports up to 1,000 VLANs and 128,000 MAC addresses.

Robust Layer 3 Capabilities

• Inter-VLAN & Static Routing: Simplifies segmentation and network traffic control.

• DHCP Services: Built-in DHCP server and relay for local networks.

• IPv4 Routes: Supports up to 256,000 IPv4 routes for large deployments.

Comprehensive Security

• ACL Support: IPv4, MAC, and IP-based access lists with up to 256 entries each.

• Advanced Protection: Includes 802.1X, DHCP snooping and guarding, storm control, and port isolation.

• IoT & Device Control: MAC-based restrictions and network isolation capabilities.

Intelligent Management and Monitoring

• Etherlighting™ Technology: Visual port activity for instant troubleshooting.

• Touchscreen LCM Display: 1.3" panel for on-device monitoring and quick access.

• Network Visibility: LLDP-MED, port mirroring, and rate limiting for enterprise-grade monitoring.

Reliable Power and Build

• Dual Power Options: 100–240V AC input and DC backup with USP RPS.

• Efficient Power Supply: Internal 200W AC/DC supply, max consumption 150W.

• Durable Construction: SGCC steel chassis and mounting brackets, NDAA compliant.

Summary / Conclusion

The Ubiquiti USW-Pro-XG-24 is the ultimate enterprise-grade switch, engineered to handle modern workloads with unmatched speed, security, and resiliency. With its mix of high-performance ports, robust Layer 3 functionality, and Etherlighting™ visibility, it delivers seamless scalability and reliability for advanced networks. Perfect for businesses, data centers, and ISPs, this switch ensures that mission-critical applications run at maximum performance with enterprise-level security and redundancy.
